Electrical Specifications

Features



  • Channel Capacity: 8 amps per channel with heatsink installed( 16 amp triacs are used.)



  • Controller Capacity: Maximum of 15 amps (about 4500 mini light)



  • Isolation: Opto isolators are used to isolate high and low voltage sides. Triacs are isolated. Parts are UL listed.



  • Supply Voltage: 120/240VAC 50/60Hz



  • Connections: Terminal Strips 20amp 12AWG max.



  • Control Input: RS485 RJ45 or RJ11











  • Director: Unit can control other units as well as its own 8 channels.



  • Input: Unit can monitor inputs to start sequences.



  • Addressing: Up to 240 possible addresses. Each address can represent up to 8000 circuits.



  • Fading: 256 levels used for smooth fading effects. Fades from 0.1 to 25 seconds.



  • Dimming: 100 levels (0% 100%)



  • Effects: Ramp, Fade, Flicker, Shimmer



  • Sequences: Multiple internal sequences



  • Presets: High-burn and low-burn settings.
