- Channel
Capacity: 8 amps per channel
with heatsink installed( 16 amp triacs are
used.)
- Board
Capacity: Maximum of 20 amps
- Isolation: Opto isolators are used to isolate high and
low voltage sides. Triacs are isolated. Parts are UL listed.
- Supply
Voltage: 120/240VAC 50/60Hz
- Connections: Terminal Strips – 20amp 12AWG max.
- Control
Input: RS485 – RJ45 or RJ11
|
- Director: Unit can control other units as well as its
own 8 channels.
- Input: Unit can monitor inputs to start sequences.
- Addressing: Up to 240 possible addresses. Each address
can represent up to 8000 circuits.
- Fading: 256 levels used for smooth fading effects.
Fades from 0.1 to 25 seconds.
- Dimming: 100 levels (0% … 100%)
- Effects: Ramp, Fade, Flicker, Shimmer
- Sequences: Multiple internal sequences
- Presets: High-burn and low-burn settings.
|
